Chevrolet Corvette C4 (1984-1998) left outside rearview mirror Wiring diagram
This page shows the only wiring diagram for the component.left outside rearview mirror, which is found in the car Chevrolet Corvette C4 (1984-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left outside rearview mirror (1 of 1)
1995 VFTC
A/C COMPRESSOR CLUTCH DIODE A/C COMPRESSOR CLUTCH
BANK #1, LEFT FRONT HEATED OXYGEN SENSOR
BANK #2, RIGHT FRONT HEATED OXYGEN SENSOR
BANK #2, RIGHT REAR HEATED OXYGEN SENSOR BANK #1, LEFT REAR HEATED OXYGEN SENSOR
BASE LEFT POWER SEAT ONLY
BASE LEFT, RIGHT POWER SEATS
BLK WIRE
BLOCKOUT SOLENOID
BLOWER MOTOR
BLOWER MOTOR CONTROL MODULE
ENGINE COOLING FAN RELAY #3
FROM CIGAR LIGHTER
HEADLAMP OPENING DOOR ACTUATOR CONTROL MODULE
LEFT DOOR COURTESY/ ILLUMINATION LAMP
LEFT FRONT MARKER LAMP LEFT FOG LAMP
LEFT FRONT PARK/ TURN LAMP LEFT UNDERHOOD LAMP
LEFT HEADLAMP
LEFT HEADLAMP DOOR ASSEMBLY
LEFT HORN
LEFT MIRROR HEATER GROUND
LEFT OUTSIDE REARVIEW MIRROR
LEFT POWER SIDE WINDOW SWITCH
LEFT SEAT ADJUSTER SWITCH
LOW BLOWER RELAY
NCA WIRE
OUTSIDE REMOTE CONTROL REARVIEW MIRROR SWITCH
POWER SEAT SWITCH DIODE
RIGHT CORNERING LAMP RIGHT HEADLAMP
RIGHT DOOR COURTESY/ ILLUMINATION LAMP
RIGHT DOOR LOCK SWITCH
RIGHT ENGINE COOLING FAN MOTOR
RIGHT FOG LAMP RIGHT HORN
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN LAMP
RIGHT HEADLAMP DOOR ASSEMBLY
RIGHT MIRROR HEATER GROUND
RIGHT OUTSIDE REARVIEW MIRROR
RIGHT POWER SIDE WINDOW SWITCH
RIGHT SEAT ADJUSTER SWITCH
RIGHT UNDERHOOD LAMP
SEAT ADJUSTER SWITCH
SEAT CONTROL MODULE
SECONDARY AIR INJECTION PUMP RELAY LEFT CORN- ERING LAMP
SPORT SEATS
W/ AUTO A/C
W/ DRL
W/ MANUAL A/C
W/ SPORT SEATS
WIND- SHIELD WASHER PUMP MOTOR LOW ENGINE OIL LEVEL SWITCH HIGH BLOWER RELAY
Go to component -> Ground distribution circuit (2 of 3) -> LEFT OUTSIDE REARVIEW MIRROR
