Chevrolet Corvette C4 (1984-1998) left heated mirror grid Wiring diagram
This page shows the only wiring diagram for the component.left heated mirror grid, which is found in the car Chevrolet Corvette C4 (1984-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left heated mirror grid (1 of 1)
#1 #4
#6 #7
A/C MODULE FUSE 1
AUTO A/C MANUAL A/C
BLK WIRE
BLOWER MOTOR
BLOWER MOTOR CONTROL MODULE
BRAKE SWITCH ASSEMBLY
BRAKE TRANSMISSION SHIFT INTERRUPT SOLENOID
BRN/WHT WIRE
BTSI FUSE 2
CNSL ILLUM FUSE 13
DK GRN/WHT WIRE
ENGINE OIL PRESSURE SENSOR/ FUEL PUMP SWITCH
F.P. 1 FUSE 14
FROM INJ 1 FUSE 22
FUEL INJECTORS
FUEL PUMP MODULE
FUEL PUMP RELAY #1
GRY WIRE
HEADLAMP SWITCH
HEATER- VENT-A/C CONTROL HEAD HEATER- VENT-A/C PROGRAMMER
HEATER- VENT-A/C CONTROL HEAD LEFT POWER WINDOW SIDE SWITCH
HEATER- VENT-A/C PROGRAMMER
HTD MIRROR FUSE 5
I/P FUSE BLOCK
INCAN- DESCENT POWER DRIVER
LEFT DOOR COURTESY/ ILLUMINATION LAMP
LEFT HEATED MIRROR GRID
LEFT OUTSIDE REAR VIEW MIRRORD
LH ILLUM FUSE 12
LIGHTED REAR VIEW MIRROR
NCA WIRE
ORG/ WIRE
OUTSIDE REMOTE CONTROL REAR VIEW MIRROR SWITCH
PNK PNK PNK WIRE
PNK WIRE
POWER- TRAIN CONTROL MODULE
PPL
RADIO CONTROL HEAD
REAR WINDOW DEFOGGER GRID
REAR WINDOW DEFOGGER RELAY
RH ILLUM FUSE 11
RIGHT DOOR COURTESY/ ILLUMINATION LAMP
RIGHT HEATED MIRROR GRID
RIGHT OUTSIDE REAR VIEW MIRRORD
RIGHT POWER WINDOW SIDE SWITCH
W/ A/T
W/ AUTO A/C
W/ MANUAL A/C
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> LEFT HEATED MIRROR GRID
