Chevrolet Corvette C4 (1984-1998) i/p fuse block ccm 3 fuse 16 wiring diagram

1995 VFTC 33 1239 INSTRUMENT CLUSTER SYSTEM AMBIENT LIGHT SENSOR (TOP LEFT SIDE OF I/P, ABOVE INSTRUMENT CLUSTER) BLK WIRE BRN WIRE CENTRAL CONTROL MODULE (CCM) (BEHIND CENTER OF I/P) CLUSTER FUSE 27 CRUISE FUSE 32 DIMMER CTRL PARK LP IN HI BEAM CTRL HIGH BEAM IN DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DRL CTRL DRL CTRL DRL CTRL DRL CTRL DRL CTRL EXTERIOR LIGHTING FUSE 6 FOG LAMP RELAY (BOTTOM RIGHT SIDE OF I/P, IN RELAY RETAINER) GRN WIRE HEAD OFF INPUT HEAD ON INPUT HEAD PARK OFF HEAD- LAMP HEAD- LAMP DIMMER SWITCH HEADLAMP RELAY HEADLAMP SWITCH HI BEAM INDICATOR HOT AT ALL TIMES HOT IN HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK CCM 3 FUSE 16 INSTRUMENT CLUSTER LEFT DRL RELAY LEFT FOG LAMP LEFT HEADLAMP DOOR ASSEMBLY LO HI LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE OFF FOG LPS SW ON INDICATOR ORG/ WIRE PARK BRAKE SWITCH (LEFT DOOR SILL, ON PARK BRAKE) PARK LAMP RELAY PNK WIRE PPL PPL/WHT WIRE RED WIRE RED/WHT WIRE RIGHT DRL RELAY RIGHT FOG LAMP RIGHT HEADLAMP DOOR ASSEMBLY RUN WIRE TAIL FUSE 6 TAN WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK #2 (LEFT REAR OF ENGINE COMPARTMENT) WHT WIRE YEL WIRE YEL/BLK WIRE
