Chevrolet Corvette C4 (1984-1998) hot in run, bulb test or start eng 1 fuse 30 Wiring diagram
This page shows the only wiring diagram for the component.hot in run, bulb test or start eng 1 fuse 30, which is found in the car Chevrolet Corvette C4 (1984-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in run, bulb test or start eng 1 fuse 30 (1 of 1)
1995 VFTC
BLK/WHT WIRE
BRAKE SWITCH ASSEMBLY
BRAKE TRANSMISSION SHIFT INTERRUPT SOLENOID (UNDER CENTER CONSOLE)
BTSI FUSE 2
DK GRN WIRE
DK GRN/WHT WIRE
HOT IN RUN, BULB TEST OR START ENG 1 FUSE 30
I/P FUSE BLOCK
ORG/BLK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (ABOVE BATTERY) BRAKE SW PARK/ NEUTRAL INPUT
PPL
PPL PPL
TAN/WHT WIRE
TRANSMISSION RANGE SWITCH (UNDER CENTER CONSOLE)
WHT WIRE
Go to component -> Shift interlock circuit -> HOT IN RUN, BULB TEST OR START ENG 1 FUSE 30
