Chevrolet Corvette C4 (1984-1998) head- lamp head- lamp wiring diagram
This page shows the only wiring diagram for the component.head- lamp head- lamp, which is found in the car Chevrolet Corvette C4 (1984-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
head- lamp head- lamp wiring diagram (1 of 1)
1995 VFTC
BLK WIRE
BRN WIRE
CENTRAL CONTROL MODULE (CCM) (BEHIND CENTER OF I/P)
CLUSTER FUSE 27
EXTERIOR LIGHTING FUSE 6
FOG LAMP RELAY (BOTTOM RIGHT SIDE OF I/P, IN RELAY RETAINER)
GRN WIRE
HEAD CB OFF PARK
HEAD OFF FOG LPS SW
HEAD- LAMP DIMMER SWITCH
HEAD- LAMP HEAD- LAMP
HEADLAMP DOORS CIRCUIT
HEADLAMP SWITCH
HI BEAM INDICATOR
HI CTRL PRK IN DM CTRL HI IN
HI LO
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
INSTRUMENT CLUSTER
LEFT FRONT FOG LAMP RIGHT HEADLAMP DOOR ASSEMBLY
LEFT HEADLAMP DOOR ASSEMBLY
LO HI LO
LT GRN WIRE
LT GRN/BLK WIRE
OFF PARK
ON INDICATOR
ORG/ WIRE
PNK WIRE
PPL
PPL/WHT WIRE
RED WIRE
RIGHT FRONT FOG LAMP
TAIL FUSE 6
TAN WIRE
UNDERHOOD FUSE BLOCK #2 (LEFT REAR OF ENGINE COMPARTMENT)
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit, without drl -> HEAD- LAMP HEAD- LAMP
