Chevrolet Corvette C4 (1984-1998) hatch fuse 45 Wiring diagrams
This page contains all the electrical diagrams for the component. hatch fuse 45, in which he is found in the car Chevrolet Corvette C4 (1984-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hatch fuse 45 (1 of 2)
1995 VFTC
BLK (OR TAN/WHT) WIRE
BLK WIRE
BLK/WHT BLK/WHT WIRE
BLK/WHT WIRE
CONSOLE DECKLID RELEASE SWITCH
DECKLID RELEASE RELAY (RIGHT SIDE OF CARGO COMPARTMENT, TAPED TO BODY HARNESS)
HATCH FUSE 45
HOT AT ALL TIMES
I/P FUSE BLOCK
LEFT DECK- LID RELEASE SOLENOID (LEFT REAR OF CARGO COMPT)
LT BLU WIRE
ORG/ WIRE
ORG/BLK WIRE
PARK BRAKE SWITCH
REAR DECKLID RELEASE SWITCH
RIGHT DECK- LID RELEASE SOLENOID (RIGHT REAR OF CARGO COMPT)
TAN/WHT WIRE
W/O DRL W/ DRL
WHT WIRE
WHT/ BLK WIRE
Go to component -> Convertible top circuit -> HATCH FUSE 45
Wiring diagram hatch fuse 45 (2 of 2)
A/C PROG FUSE 43
ACCY PLUG
AIR PUMP
ANTENNA MOTOR
BASE LEFT SEAT
BLK WIRE
BOSE RELAY ANTENNA MOTOR
BRAKE LAMP CAPACITOR BRAKE SWITCH ASSEMBLY
BREAKER
CARGO COMPARTMENT LAMPS
CCM 2 FUSE 39
CENTRAL CONTROL MODULE
CIGAR FUSE 44
CIGAR LIGHTER
CONVERTIBLE COUPE
COURTESY LAMP RELAY INSTRUMENT CLUSTER TONE GENER- ATOR
DATA LINK CONNECTOR
DECK LID RELEASE RELAY
DOOR COURTESY ILLUMINATION LAMPS
DRIVER INFOR- MATION CENTER
ENGINE COOLING FAN RELAY #1
ENGINE COOLING FAN RELAY #2
EXTERIOR LIGHTING
FOOTWELL COURTESY LAMPS
FROM BATTERY
FUSE 1
FUSE 2
FUSE 3
FUSE 4
FUSE 40
FUSE 41
FUSE 42
FUSE 5
FUSE 6
FUSE 7
FUSE 8
HATCH FUSE 45
HATCH RELEASE RELAY
HEADLAMP OPENING DOOR ACTUATOR CONTROL MODULE
HEADLAMP SWITCH
HEADLAMP SWITCH HAZARD FLASHER
HEATER- VENT-A/C PROGRAMMER
HORN FUSE 7
HORN RELAY
I/P FUSE BLOCK L.C.D. FUSE 38 (FAR RIGHT SIDE OF I/P)
INTERIOR LIGHTING
LEFT, RIGHT SEATS
LH CTSY FUSE 37
LH HDLP MOTOR
LH RH RH
LIGHTED REARVIEW MIRROR CONSOLE GLOVE COMPARTMENT LAMP
LINE FUSE
NCA WIRE
ORG/ WIRE
PASSIVE KEYLESS ENTRY MODULE
POWER ACCSY
POWER LOCK
POWER SEAT CIRCUIT
PRIMARY COOLING FAN
RADIO CONTROL HEAD
RADIO FREQUENCY CHOKES
RADIO RECEIVER DAYTIME RUNNING LAMPS MODULE
RDO BATT
RED WIRE
RH CTSY FUSE 36
RH HDLP MOTOR
RIGHT DOOR LOCK SWITCH LEFT DOOR LOCK SWITCH
SEAT CONTROL MODULE SEAT SELECT SWITCH
SEAT SWITCH DIODE
SEAT SWITCH DIODE SEAT SWITCH DIODE
SECONDARY AIR INJECTION BLEED VALVE SOLENOID
SECONDARY AIR INJECTION PUMP
SECONDARY COOLING FAN
SPORT SEAT
STOP HAZ
TAIL FUSE 6
UNDERHOOD FUSE BLOCK 2
UNDERHOOD LAMPS
UNDERHOOD LIGHTS IN-
W/ AUTO A/C
W/ DRL
W/ SPORT SEATS
W/O BOSE
WIRE END TAPED TO I/P HARNESS, UNDER CENTER CONSOLE
Go to component -> Power distribution circuit (2 of 4) -> HATCH FUSE 45
