Chevrolet Corvette C4 (1984-1998) cruise fuse 32 10 amp cluster fuse 27 5 amp Wiring diagram

ABS ACTIVE IND. AIR BAG IND AMBIENT LIGHT SENSOR AMBIENT LIGHT SENSOR INPUT ANTI-LOCK BRAKES SYSTEM ASR ACTIVE IND. ASR OFF IND. BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CENTRAL CONTROL MODULE (BEHIND CENTER OF I/P) LOW OIL IND. CTRL CHECK CHARGING SYSTEM IND. CRUISE FUSE 32 10 AMP CLUSTER FUSE 27 5 AMP DATA LINK CONNECTOR (LEFT OF STEERING COLUMN) DIAGNOSTIC ENABLE DIC SWITCH INPUT DK BLU WIRE DK GRN/WHT WIRE DRIVER INFORMATION CENTER (DIC) ENG/ MET FUEL INFO FUEL RESET DIC SWITCHES GAUGES GENERATOR REAL TIME DAMPING MODULE (LEFT CARGO COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK (FAR RIGHT SIDE OF I/P) IGN IND CTRL IND. CTRL IND. CTRL LOW COOLANT IND LOW COOLANT SWITCH LOW ENGINE OIL LEVEL SWITCH LOW OIL LOW OIL IND LOW OIL LEVEL INPUT LOW TIRE PRESSURE WARNING MODULE (BEHIND CENTER OF I/P) LOW TIRE PRESSURE WARNING SENSOR ASSEMBLY LOW/FLAT TIRE IND. LT GRN WIRE MIL IND. CTRL NCA WIRE ORG/ WIRE PASSIVE KEYLESS ENTRY IND. PNK PNK WIRE PNK WIRE POWER LOCK FUSE 42 20 AMP POWERTRAIN CONTROL MODULE (LEFT REAR ENGINE COMPT) PPL PPL/WHT WIRE RECEIVE INPUT REF GND SERVICE ABS IND. SERVICE ASR IND. SERVICE ENGINE SOON IND SERVICE LTPWS IND. SERVICE RIDE CONTROL IND. SOLID STATE (4) (MOUNTED INSIDE EACH TIRE, STRAPPED TO WHEEL ASSEMBLY) SWITCH ILLUM. TRIP RESET TRIP/ ODO WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
