Chevrolet Corvette C4 (1984-1998) cluster fuse 27 Wiring diagram
This page shows the only wiring diagram for the component.cluster fuse 27, which is found in the car Chevrolet Corvette C4 (1984-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cluster fuse 27 (11 of 11)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CENTRAL CONTROL MODULE (BEHIND CENTER OF I/P) CHIME OUT CONTROL
CHIME 1 INPUT CHIME 2 INPUT
CLUSTER FUSE 27
DK BLU/WHT WIRE
EXTERIOR LIGHTS SYSTEM PPL
FASTEN BELTS INDIC CTRL
GRN WIRE
GRY/BLK WIRE
HEAD
HEAD- LAMP SWITCH
HEAD/PARK SWITCH IN
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
INSTRUMENT CLUSTER
KEY-IN IGNITION IN
LCD FUSE 38
LEFT DOOR AJAR KEY-IN IGNITION SWITCH
LEFT DOOR IN
LT GRN WIRE
NCA WIRE
OFF PARK
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (LEFT REAR OF ENGINE COMPT, ABOVE BATTERY)
PPL
REMOTE KEYLESS ENTRY SYSTEM
RIGHT DOOR AJAR SEAT BELT SWITCH
SEAT BELT SWITCH IN RIGHT DOOR IN
SEAT BELTS INDIC
SUPPLEMENTAL RESTRAINT SYSTEM
SWITCH
TONE GENERATOR (BEHIND CENTER OF I/P) POWER
TURN FLASH IN
TURN FLASHER
TURN FUSE 24
VEHICLE SPEED OUTPUT
VSS IN
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits -> CLUSTER FUSE 27
