Chevrolet Corvette C4 (1984-1998) arm utd output door key sw out program request utd status input key in ign input Wiring diagram

1995 VFTC A/T ACCY ARM UTD OUTPUT DOOR KEY SW OUT PROGRAM REQUEST UTD STATUS INPUT KEY IN IGN INPUT BLK WIRE BLK/WHT WIRE BRN WIRE BULB TEST CENTRAL CONTROL MODULE (CCM) (BEHIND CENTER OF I/P) CLUTCH PEDAL POSITION SWITCH (MOUNTED TO TOP OF CLUTCH PEDAL) DK GRN WIRE DOOR LOCKS SYSTEM GRY WIRE GRY/BLK WIRE HATCH DOOR AJAR SWITCH (COUPE) HEAD HEADLAMP SWITCH HORN SYSTEM (HORN RELAY) HOT AT ALL TIMES I/P FUSE BLOCK I/P FUSE BLOCK CRANK P/N CLUTCH FUSE 10 IGNITION KEY IGNITION KEY LOCK CYLINDER IGNITION SWITCH INSTRUMENT CLUSTER INTERIOR LIGHTS SYSTEM (DIODE MODULE) KEY RESISTOR INPUT SERIAL DATA 1 START ENABLE RLY GROUND KEY-IN IGNITION SWITCH LCD FUSE 38 LEFT DOOR AJAR SWITCH LEFT DOOR KEY SWITCH LOCK OFF LT DOOR UNLK OUT LK BOTH DOOR OUT LT GRN WIRE M/T M/T PPL NCA WIRE OFF PARK ORG/ WIRE PASSIVE KEYLESS ENTRY MODULE (BEHIND CENTER OF I/P) PPL PPL A/T PPL/WHT WIRE RED/BLK WIRE RESISTOR PELLET RIGHT DOOR AJAR SWITCH RIGHT DOOR KEY SWITCH RUN WIRE SECURITY INDICATOR SERIAL DATA STARTER SOLENOID TAN WIRE THEFT DETERRENT RELAY (BELOW LEFT SIDE OF I/P, LEFT OF STEERING COLUMN) TRANSMISSION RANGE SWITCH (IN CONSOLE, AT BASE OF SHIFT CONTROL LEVER) UTD STATUS OUT PROGRAM REQUEST OUT SERIAL DATA 2 WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
