Chevrolet Corvette C4 (1984-1998) 1381 1382 lcd display feed control button led illumination ground Wiring diagram

1381 1382 LCD DISPLAY FEED CONTROL BUTTON LED ILLUMINATION GROUND 1995 VFTC A/C BLOWER FUSE 4 A/C CLUTCH FUSE 18 A/C MDL FUSE 1 A/C PROG FUSE 43 BLK WIRE BLOWER MOTOR BLOWER MOTOR CONTROL MODULE (RIGHT REAR OF ENGINE COMPARTMENT) BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN RUN HVAC CONTROL HEAD HVAC PROGRAMMER (BELOW LEFT SIDE OF I/P, RIGHT OF STEERING COLUMN) I/P FUSE BLOCK INSIDE AIR TEMPERATURE SENSOR (BEHIND RIGHT SIDE OF I/P) LT BLU WIRE LT BLU/BLK WIRE LT GRN/BLK WIRE MIX VALVE FEEDBK SUN LOAD SENSOR INSIDE TEMP SENSOR OUTSIDE TEMP SENSOR NCA WIRE ORG/ WIRE OUTSIDE TEMPERATURE SENSOR (IN RIGHT RADIATOR SHROUD) PPL PPL/WHT WIRE REAR DEFOGGER SYSTEM RED WIRE SOLAR SENSOR (TOP CENTER OF I/P) TAN WIRE TEMPERATURE DOOR MOTOR (BEHIND RIGHT SIDE OF I/P, ON BOTTOM HEATER CASE) UNDERHOOD FUSE BLOCK 1 YEL WIRE
