Car Wiring Diagrams for Supplemental restraint circuit for Chevrolet Corsica I (1987-1996)

2.49 5.1 8.45 BLK WIRE BLK/WHT WIRE BRN WIRE CONVENIENCE CENTER (LEFT SIDE OF I/P, ABOVE FUSE BLOCK) CRANK INPUT DATA LINK CONN (DLC) (LEFT SIDE OF I/P) DIAGNOSTIC ENERGY RESERVE MODULE (DERM) (BEHIND RIGHT FRONT KICK PANEL) DK GRN WIRE DRIVER SEAT BELT DRIVER SIDE "HIGH" DRIVER SIDE "LOW" DRIVER SOURCE SENSE ENGINE CONTROLS FORWARD DISCRIMINATING SENSOR (ATTACHED TO RADIATOR SUPPORT) FUSE 3 FUSE 9 FUSE BLOCK GROUND GRY WIRE HOT IN RUN, BULB TEST OR START IGN 1 INITIATOR MODULE INSTRUMENT CLUSTER AIR BAG IND LT GRN WIRE MULTI- FUNCTION ALARM MODULE LEFT FRONT SEAT BELT INPUT NCA WIRE PASSENGER COMPARTMENT DISCRIMINATING SENSOR (UNDER CENTER CONSOLE) PNK WIRE PPL/WHT WIRE REDUNDANT IND GROUND SEAT BELT SW- SERIAL DATA LINE SHORTING BAR SIR COIL ASSEMBLY (TOP OF STEERING COLUMN) SIR INDICATOR CTRL PNK REDUNDANT IND IGN 1 WIRE TAN WIRE WHT WIRE YEL WIRE YEL/BLK WIRE
