Courtesy lamps circuit for Chevrolet Corsica I (1987-1996)
Courtesy lamps circuit
1995 VFTC
BATT GND
BLK WIRE
CIGAR LIGHTER SWITCH
CONVENIENCE CENTER (LEFT SIDE OF I/P, ABOVE FUSE BLOCK)
DIMMER SWITCH
DOME LIGHT
FUSE 11
FUSE 6
FUSE 9
FUSE BLOCK (BEHIND LEFT SIDE OF I/P)
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
INTERIOR LTS CTRL
LEFT FOOTWELL COURTESY LIGHT
LEFT FRONT DOOR HANDLE SWITCH (IN LEFT FRONT DOOR LATCH ASSEMBLY)
LEFT REAR DOOR JAMB SWITCH (IN CENTER PILLAR)
LIGHT SWITCH
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LUGGAGE COMPARTMENT LIGHT
MULTI-FUNCTION ALARM MODULE
NCA WIRE
OFF
OFF ON
ORG/ WIRE
OVERHEAD LIGHTS
PARASITIC PWR CTRL
PNK WIRE
READING LIGHTS
REAR DR OPN IN RIGHT FNT DR OPN IN LEFT FNT DR OPN IN IGN
RIGHT FOOTWELL COURTESY LIGHT
RIGHT FRONT DOOR HANDLE SWITCH (IN RIGHT FRONT DOOR LATCH ASSEMBLY)
RIGHT REAR DOOR JAMB SWITCH (IN CENTER PILLAR)
SEDAN ONLY
WHT WIRE
YEL WIRE
