Chevrolet Corsica I (1987-1996) passenger compartment discriminating sensor Wiring diagram
This page shows the only wiring diagram for the component.passenger compartment discriminating sensor, which is found in the car Chevrolet Corsica I (1987-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger compartment discriminating sensor (1 of 1)
A/C BLOWER COMPRESSOR MOTOR CLUTCH RELAY
A/C CLUTCH DIODE
ABS LAMP MODULE
B/H CONN
BATTERY
BLK WIRE
BLK/WHT WIRE
BRAKE FLUID BLOWER LEVEL MOTOR SWITCH
BRAKE TRANSAXLE SHIFT INTERLOCK SOLENOID (A/T)
CRANKCASE VENT HEATER
CRUISE CONTROL MODULE
CRUISE CONTROL SERVO
DATA FUEL LINK PUMP CONN RELAY
DAYTIME RUNNING LIGHTS MODULE
DIAGNOSTIC ENERGY RESERVE MODULE
ELECTRONIC BRAKE CONTROL MODULE
ELECTRONIC IGNITION SYSTEM
ENGINE CONTROL INSTRUMENT MODULE CLUSTER
ENGINE DATA INSTRUMENT CONTROL LINK CLUSTER MODULE CONN
FORWARD DISCRIMINATING SENSOR
FUEL PUMP RELAY
HEATED OXYGEN SENSOR
HEATER, A/C CONTROL ASSEMBLY
IGNITION
INSTRUMENT
LIGHT SW
LOW COOLANT SWITCH
MULTI-FUNCTION ALARM MODULE
NCA WIRE
OIL LEVEL COOLANT SWITCH FAN
ON DASH PANEL)
PASSENGER COMPARTMENT DISCRIMINATING SENSOR
RADIO
REAR DEFOGGER CONTROL, POWER WIPER/ UNLOCK WASHER SW MODULE
RIGHT FRONT LEFT FRONT ABS ABS SOLENOID SOLENOID
TAN WIRE
TAN/WHT WIRE
TEMP VALVE MOTOR SW
Go to component -> Ground distribution circuit (1 of 2) -> PASSENGER COMPARTMENT DISCRIMINATING SENSOR
