Chevrolet Corsica I (1987-1996) cruise engage output Wiring diagram
This page shows the only wiring diagram for the component.cruise engage output, which is found in the car Chevrolet Corsica I (1987-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise engage output (1 of 1)
396 LT BLU/BLK WIRE
400 YEL WIRE
401 PPL
817 DK GRN/WHT WIRE
A/T
BLK WIRE
BLU WIRE
BRAKE SW (ON BRAKE PEDAL SUPPORT)
BRN WIRE
BRN/WHT WIRE
CRUISE CONTROL CLUTCH SW (ON CLUTCH PEDAL SUPPORT)
CRUISE CONTROL MODULE (BEHIND RIGHT SIDE OF INST. PANEL, ABOVE GLOVE BOX)
CRUISE CONTROL SERVO (REAR OF ENGINE COMPT CENTER OF DASH PANEL)
CRUISE ENGAGE OUTPUT
CRUISE ENGAGED INPUT 4000 PULSES/MILE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
FUSE BLOCK #14
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOT IN ACCY OR RUN
INSTRUMENT CLUSTER
LT BLU/BLK WIRE
M/T
MULTIFUNCTION LEVER
OFF
OFF ON
ON INPUT
PPL
R/A
RED WIRE
SERVO POSITION SENSOR
SERVO POSTN INPUT BRAKE INPUT GROUND GROUND
SET SW
TAN WIRE
VACUUM VALVE
VACUUM VALVE CTRL SET/COAST INPUT RESUME/ACCEL INPUT
VENT VALVE
VENT VALVE CTRL VSS INPUT
VSS INPUT
VSS INPUT/LO VSS INPUT/HI
WIPER MOTOR ASSEMBLY MULTI/FUNCTION ALARM MODULE
YEL WIRE
Go to component -> Cruise control circuit -> CRUISE ENGAGE OUTPUT
