Chevrolet Corsica I (1987-1996) console ashtray light Wiring diagram
This page shows the only wiring diagram for the component.console ashtray light, which is found in the car Chevrolet Corsica I (1987-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram console ashtray light (1 of 1)
1995 VFTC
BLK WIRE
CANADIAN MODELS ONLY
CONSOLE ASHTRAY LIGHT
CONSOLE SHIFT LIGHT
CONVIENCE CENTER (LEFT SIDE OF I/P, ABOVE FUSE BLOCK)
COUPE ONLY
DAYTIME RUNNING LIGHTS (DRL) MODULE (RIGHT SIDE OF I/P, ABOVE GLOVE BOX)
DISPLAY DIM SIGNAL
DK GRN WIRE
EXTERIOR LIGHTS SYSTEM (REAR LIGHTS)
FUSE 13
FUSE BLOCK (BEHIND LEFT SIDE OF I/P)
GRY WIRE
HEADLIGHT SWITCH
HEATER, A/C CONTROL ASSEMBLY
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LIGHT SWITCH
LIGHT SWITCH LIGHT
MULTI-FUNCTION ALARM MDULE
OFF HEAD PARK
PWM MODULE
RADIO
REAR DEFOGGER CONTROL, WIPER/WASHER SWITCH
SEDAN ONLY
W/REAR DEFOGGER
Go to component -> Instrument illumination circuit -> CONSOLE ASHTRAY LIGHT
