Chevrolet Colorado III (2023-2024) sunload temperature, ambient light, security indicator sensor Wiring diagram
This page shows the only wiring diagram for the component.sunload temperature, ambient light, security indicator sensor, which is found in the car Chevrolet Colorado III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sunload temperature, ambient light, security indicator sensor (1 of 1)
A/C COMPRESSOR SOL VLV CTRL
A/C EVAPORATOR TEMP SENS SIG
AIR CONDITIONING COMPRESSOR RELAY
AIR CONDITIONING EVAPORATOR AIR TEMPERATURE SENSOR
ANTI-THEFT SYSTEM
AUTOSAR CAN BUS (-) 9 SERIAL DATA
BATT POS VOLT
BATTERY DISTRIBUTION ENGINE COMPARTMENT FUSE BLOCK
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR (RIGHT SIDE OF DASH)
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BLWR MTR SPD CTRL
BLWR SPD FEEDBACK SIG
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SOLAR SENS SIG
ENGINE CONTROLS IGNITION RELAY
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN/BLU WIRE
GRY WIRE
GRY/GRN WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
HVAC REM ENABLE SIG
HVAC SYS ENABLE SIG
INSIDE AIR TEMP SENS SIG
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LOGIC
RED/BRN WIRE
RED/GRY WIRE
RED/WHT WIRE
SENS LO REF
SUNLOAD TEMPERATURE, AMBIENT LIGHT, SECURITY INDICATOR SENSOR
VIO/BLU WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/YEL WIRE
Go to component -> Manual a/c circuit (1 of 4) -> SUNLOAD TEMPERATURE, AMBIENT LIGHT, SECURITY INDICATOR SENSOR
