Chevrolet Colorado III (2023-2024) all windows open serial data Wiring diagram
This page shows the only wiring diagram for the component.all windows open serial data, which is found in the car Chevrolet Colorado III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram all windows open serial data (1 of 1)
ALL WINDOWS OPEN SERIAL DATA
AUTOSAR CAN BUS (-) 9 SERIAL DATA
BLK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DOWN
DRIVER FRONT SIDE DOOR WINDOW CONTROL SWITCH
DRIVER FRONT SIDE DOOR WINDOW REGULATOR MOTOR
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN/BLK WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
HAZARD WARNING SWITCH
HOT AT ALL TIMES
ILL
LEFT REAR SIDE DOOR WINDOW REGULATOR MOTOR
LEFT REAR SIDE DOOR WINDOW SWITCH
LOGIC
LOGIC ILL
PASSENGER FRONT SIDE DOOR WINDOW REGULATOR MOTOR
PASSENGER FRONT SIDE DOOR WINDOW SWITCH
RED/BLU WIRE
RED/GRY WIRE
RIGHT REAR SIDE DOOR WINDOW REGULATOR MOTOR
RIGHT REAR SIDE DOOR WINDOW SWITCH
WHT/GRN WIRE
WINDOW LIFT IND
WINDOW LIFT SWITCH
YEL WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Power windows circuit, w/o express up/down -> ALL WINDOWS OPEN SERIAL DATA
