Wiper/washer circuit for Chevrolet Colorado I (2004-2012)
Wiper/washer circuit
BLK WIRE
BODY CONTROL MODULE (BEHIND RIGHT KICK PANEL)
BRN WIRE
DK GRN WIRE
GRY WIRE
HI IN
HOT AT ALL TIMES
LO IN
LT BLU WIRE
MIST
NCA WIRE
OFF
OFF INT WIPER SWITCH
PARK OUT
PPL
RAP RELAY
RAP RELAY COIL CONTROL
RED WIRE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT)
WASHER SWITCH
WINDSHIELD WASHER FLUID PUMP (ON WASHER FLUID RESERVOIR)
WINDSHIELD WASHER PUMP CONTROL
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER MOTOR PARK SWITCH SIGNAL
WINDSHIELD WIPER SWITCH SIGNAL 1
WINDSHIELD WIPER SWITCH SIGNAL 2
WINDSHIELD WIPER/ WASHER SWITCH
WPR 2 RELAY
WPR FUSE
WPR RELAY
WSW FUSE
YEL WIRE
