Charging circuit for Chevrolet Colorado I (2004-2012)
Charging circuit
B+ FIELD DUTY CYC B+ GEN TURN ON
BATTERY
BLK WIRE
BLK/WHT WIRE
CHARGE IND
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER (DIC) DISPLAY
FIELD DUTY CYC
GENERATOR
GENERATOR BATTERY CONTROL MODULE (LEFT FRONT OF ENGINE COMPT, NEAR BATTERY)
GROUND
GROUND GEN REG CNTRL SERIAL DATA PPL PPL
GRY WIRE
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
MEGA FUSE
ORG/ WIRE
POWER DISTRIBUTION
PPL
PPL GEN REG CNTRL
PPL SERIAL DATA
RED WIRE
RVC FUSE
STARTER
SYSTEM
UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT)
