Power windows circuit, 2 door for Chevrolet Colorado I (2004-2012)
Power windows circuit, 2 door
4 11 5 12 PPL
AUTO DOWN LOGIC
BLK WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DOWN LOGIC
DOWN PCB RELAY
DOWN RELAY
DR/LCK FUSE
DRIVER DOOR LOCK/ WINDOW SWITCH
DRIVER WINDOW MOTOR (IN LOWER FRONT OF DOOR)
HOT AT ALL TIMES
HOT W/ RAP RELAY ENERGIZED
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER DOOR LOCK/ WINDOW SWITCH
PASSENGER WINDOW MOTOR (IN LOWER FRONT OF DOOR)
PWR/ WNDW FUSE
RF DOWN IGN
RF UP
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT)
UP PCB RELAY
UP RELAY
YEL WIRE
