Passenger"s heated seat circuit for Chevrolet Colorado I (2004-2012)

Passenger"s heated seat circuit

Get access

2009-GM-29-27 302576 A/C FUSE BLK WIRE BLK/RED WIRE BODY CONTROL MODULE (BCM) (BEHIND RIGHT KICK PANEL) BRN WIRE FRONT PASSENGER HEATED SEAT MODULE (BOTTOM OF FRONT PASSENGER SEAT) GND B+ HI/LO SIG SPLY VOLT HIGH/LOW STATUS IND BULB HOT AT ALL TIMES HTD/SEAT FUSE IGN 3 IGN 3 HVAC RELAY IGN 3 VOLTAGE LOGIC LT BLU WIRE NCA WIRE ORG/ WIRE PASSENGER BACK HEATED SEAT ELEMENT PASSENGER CUSHION HEATED SEAT ELEMENT PASSENGER SEAT LUMBAR ADJUSTER SWITCH PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RT SEAT BELT SW SUPPLEMENTAL RESTRAINTS SYSTEM TEMP SENS SIG UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT) YEL WIRE
