Driver heated seat circuit for Chevrolet Colorado I (2004-2012)
Driver heated seat circuit
2009-GM-29-26 302575
A/C FUSE
BLK WIRE
BLK/RED WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT KICK PANEL)
BRN WIRE
DRIVER BACK HEATED SEAT ELEMENT
DRIVER CUSHION HEATED SEAT ELEMENT
DRIVER HEATED SEAT MODULE (BOTTOM OF DRIVER SEAT)
DRIVER SEAT LUMBAR ADJUSTER SWITCH
GND B+ HI/LO SIG SPLY VOLT
HIGH/LOW STATUS IND BULB
HOT AT ALL TIMES
HTD/SEAT FUSE
IGN 3 HVAC RELAY
IGN 3 VOLTAGE
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
TEMP SENS SIG
UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT)
YEL WIRE
