Chevrolet Colorado I (2004-2012) temp sens sig Wiring diagrams
This page contains all the electrical diagrams for the component. temp sens sig, in which he is found in the car Chevrolet Colorado I (2004-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram temp sens sig (1 of 2)
2009-GM-29-26 302575
A/C FUSE
BLK WIRE
BLK/RED WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT KICK PANEL)
BRN WIRE
DRIVER BACK HEATED SEAT ELEMENT
DRIVER CUSHION HEATED SEAT ELEMENT
DRIVER HEATED SEAT MODULE (BOTTOM OF DRIVER SEAT)
DRIVER SEAT LUMBAR ADJUSTER SWITCH
GND B+ HI/LO SIG SPLY VOLT
HIGH/LOW STATUS IND BULB
HOT AT ALL TIMES
HTD/SEAT FUSE
IGN 3 HVAC RELAY
IGN 3 VOLTAGE
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
TEMP SENS SIG
UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Driver heated seat circuit -> TEMP SENS SIG
Wiring diagram temp sens sig (2 of 2)
2009-GM-29-27 302576
A/C FUSE
BLK WIRE
BLK/RED WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT KICK PANEL)
BRN WIRE
FRONT PASSENGER HEATED SEAT MODULE (BOTTOM OF FRONT PASSENGER SEAT)
GND B+ HI/LO SIG SPLY VOLT
HIGH/LOW STATUS IND BULB
HOT AT ALL TIMES
HTD/SEAT FUSE
IGN 3
IGN 3 HVAC RELAY
IGN 3 VOLTAGE
LOGIC
LT BLU WIRE
NCA WIRE
ORG/ WIRE
PASSENGER BACK HEATED SEAT ELEMENT
PASSENGER CUSHION HEATED SEAT ELEMENT
PASSENGER SEAT LUMBAR ADJUSTER SWITCH
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RT SEAT BELT SW
SUPPLEMENTAL RESTRAINTS SYSTEM
TEMP SENS SIG
UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Passenger"s heated seat circuit -> TEMP SENS SIG
