Chevrolet Colorado I (2004-2012) rt sig lps ctrl Wiring diagram
This page shows the only wiring diagram for the component.rt sig lps ctrl, which is found in the car Chevrolet Colorado I (2004-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rt sig lps ctrl (1 of 1)
AUTO
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT KICK PANEL)
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK GRN WIRE
FRT PRK LAMP FUSE
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HAZARD SW SIG
HAZARD SWITCH
HEAD PARK
HEADLAMP, PANEL DIMMER SWITCH
HOT AT ALL TIMES
LEFT
LEFT CARGO LAMP
LEFT CENTER HIGH MOUNTED STOP LAMP (CHMSL)
LEFT FRONT PARK LAMP
LEFT PARK/ TURN SIGNAL LAMP
LR TURN SIG LPS CTRL
LT BLU WIRE
LT SIG LPS CTRL
OFF PPL
ORG/ WIRE
PPL LOW REF
PRK LAMP RELAY
PRK LP RLY CTRL
PRK LP RLY CTRL TURN SIG SW SIG
RED WIRE
RIGHT
RIGHT CARGO LAMP
RIGHT CENTER HIGH MOUNTED STOP LAMP (CHMSL)
RIGHT FRONT PARK LAMP INTERIOR LIGHTS SYSTEM
RIGHT PARK/ TURN SIGNAL LAMP
RR TURN SIG LPS CTRL
RT SIG LPS CTRL
TO REAR PRK LAMP 2 FUSE
TRAILER POWER FUSE
TRAILER PROVISION (BLUNT CUT)
TURN SIGNAL/ MULTI-FUNCTION SWITCH
TURN/ HAZRD FRT FUSE
TURN/ HAZRD REAR FUSE
UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT)
VIO WIRE
W/ TRAILER CONNECTER
W/O TRAILER CONNECTER
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> RT SIG LPS CTRL
