Chevrolet Colorado I (2004-2012) right front park lamp Wiring diagram
This page shows the only wiring diagram for the component.right front park lamp, which is found in the car Chevrolet Colorado I (2004-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front park lamp (1 of 1)
BLK WIRE
BREAKOUT)
CREW CAB W/ POWER OPERATED WINDOW
DRIVER BACK HEATED SEAT ELEMENT
DRIVER CUSHION HEATED SEAT ELEMENT
DRIVER HEATED SEAT CONTROL MODULE
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR ADJUSTER SWITCH
FROM
FUEL PUMP FLOW CONTROL MODULE
HORN ASSEMBLY
HVAC RIGHT REAR CONTROL WINDOW MODULE SWITCH
LEFT BACKUP LAMP
LEFT CARGO LAMP
LEFT CENTER HIGH MOUNTED STOP LAMP (CHMSL)
LEFT FRONT FOG LAMP
LEFT FRONT PARK LAMP
LEFT LEFT TAIL/STOP TAIL/TURN LAMP SIGNAL LAMP
LEFT PARK/TURN SIGNAL LAMP
NCA WIRE
PASSENGER CUSHION HEATED SEAT ELEMENT
PASSENGER PASSENGER HEATED BACK HEATED SEAT SEAT CONTROL ELEMENT MODULE
PASSENGER SEAT PASSENGER SEAT ADJUSTER LUMBAR ADJUSTER SWITCH SWITCH
RIGHT BACKUP LAMP
RIGHT CARGO LAMP
RIGHT CENTER HIGH MOUNTED STOP LAMP (CHMSL)
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK LAMP
RIGHT LEFT LICENSE LICENSE LAMP LAMP
RIGHT PARK/TURN SIGNAL LAMP
RIGHT TAIL/ TURN SIGNAL LAMP
RIGHT TAIL/STOP LAMP
STOP LAMP SWITCH
TRAILER LIGHTING CONVERTER
TRANSFER CASE SHIFT CONTROL MODULE
UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT) FOG LAMP RELAY
W/ DRIVER POWER SEAT
W/ TRAILER CONNECTOR
W/O TRAILER CONNECTOR
WHT WIRE
Go to component -> Ground distribution circuit (2 of 3) -> RIGHT FRONT PARK LAMP
