Chevrolet Colorado I (2004-2012) ppl serial data right aud sig left aud sig common sig left aud sig common sig Wiring diagram
This page shows the only wiring diagram for the component.ppl serial data right aud sig left aud sig common sig left aud sig common sig, which is found in the car Chevrolet Colorado I (2004-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl serial data right aud sig left aud sig common sig left aud sig common sig (1 of 1)
2 1 8 LEFT AUDIO SIG AUDIO COMM SIG DRAIN WIRE
6 SPEAKERS SYSTEM)
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CAB, CREW CAB)
COAX
COAX COAX SATELLITE IN
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
DIGITAL RADIO RECEIVER (IF EQUIPPED) (CENTER OF DASH)
DIGITAL VIDEO DISC (DVD) CONTROL MODULE INLINE FUSE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRAIN WIRE
EXTENDED CAB CREW CAB
FUSE
GROUND COMMON SIG
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT) RDO FUSE
LEFT AUD SIG RIGHT AUD SIG
LEFT FRONT SPEAKER
LEFT FRONT TWEETER SPEAKER (W/
LEFT REAR SPEAKER (W/ EXTENDED
LF OUT - LF OUT + RR OUT + RR OUT - GROUND B+
LR OUT - LR OUT + RF OUT + RF OUT -
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PPL PPL 1807 1807
PPL SERIAL DATA
PPL SERIAL DATA RIGHT AUD SIG LEFT AUD SIG COMMON SIG LEFT AUD SIG COMMON SIG
RADIO
RADIO ANTENNA
RIGHT FRONT SPEAKER
RIGHT FRONT TWEETER SPEAKER (W/
RIGHT REAR SPEAKER (W/ EXTENDED
SERIAL DATA (-) SERIAL DATA (+)
TAN WIRE
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (W/ ONSTAR) (RIGHT SIDE OF DASH)
W/ SPO DVD
W/O SPO DVD
YEL WIRE
Go to component -> Radio circuit -> PPL SERIAL DATA RIGHT AUD SIG LEFT AUD SIG COMMON SIG LEFT AUD SIG COMMON SIG
