Chevrolet Colorado I (2004-2012) left turn ind logic Wiring diagram
This page shows the only wiring diagram for the component.left turn ind logic, which is found in the car Chevrolet Colorado I (2004-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left turn ind logic (1 of 1)
A/T
ACCELERATOR PEDAL POSITION SWITCH BREAKOUT)
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENGINE COMPT)
ENGINE CONTROL MODULE (ECM) (RIGHT REAR OF
FROM FRT PRK LAMP FUSE (DIAGRAM
GRN WIRE
HOT AT ALL TIMES
INLINE FUSE TRAILER CONNECTOR
INLINE FUSE TRAILER LIGHTING CONVERTER
INSTRUMENT PANEL CLUSTER (IPC)
LAMP
LEFT BACKUP LAMP
LEFT TAIL/ STOP
LEFT TAIL/ TURN SIGNAL LAMP
LEFT TURN IND LOGIC
LOGIC TRAILER LIGHTING CONVERTER (IF EQUIPPED)
LT BLU WIRE
LT GRN WIRE
POWER DISTRIBUTION SYSTEM
REAR PRK LAMP 2 FUSE
REAR PRK LAMP FUSE
RED WIRE
RIGHT BACKUP LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT TAIL/
RIGHT TAIL/ TURN SIGNAL LAMP
RIGHT TURN IND
STOP FUSE
STOP LAMP
STOP LAMP SWITCH
STP LMP VLT
TAN WIRE
TRAILER CONNECTOR
TRAILER PROVISION (BLUNT CUT)
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT)
VSES STOP RELAY
W/ TRAILER CONNECTER
W/O TRAILER CONNECTER
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> LEFT TURN IND LOGIC
