Chevrolet Colorado I (2004-2012) left tail/turn signal lamp Wiring diagram
This page shows the only wiring diagram for the component.left tail/turn signal lamp, which is found in the car Chevrolet Colorado I (2004-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left tail/turn signal lamp (1 of 1)
A/C CMPRSR FUSE
A/C RELAY
BACKUP LAMP RELAY
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
BODY CONTROL MODULE (BCM) 5 VOLT
BRN WIRE
COMPT)
CONVERTER INLINE FUSE
CREW CAB W/ POWER
DRIVER DOOR LOCK/ WINDOW SWITCH
FROM RUN/ CRANK RELAY (DIAGRAM 2 OF 4)
FROM RUN/CRANK RELAY (DIAGRAM 2 OF 4)
FROM SPLICE
FRT PRK LAMP FUSE
GRN WIRE
IGNITION SWITCH
IGNITION VOLT
INPUT MULTI-FUNCTION SWITCH
KEY-IN IGNITION SWITCH
LEFT FRONT MARKER LAMP
LEFT LICENSE LAMP
LEFT PARK/TURN SIGNAL LAMP
LEFT REAR WINDOW SWITCH
LEFT TAIL/STOP LAMP
LEFT TAIL/TURN SIGNAL LAMP
LIGHTING CONNECTOR)
OFF OFF
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH (IF EQUIPPED)
PASSENGER DOOR LOCK/ WINDOW SWITCH
PRK/LAMP RELAY
REAR PRK LAMP 2 FUSE
REAR PRK LAMP FUSE
RED WIRE
RIGHT FRONT MARKER LAMP
RIGHT LICENSE LAMP
RIGHT PARK/TURN SIGNAL LAMP
RIGHT REAR WINDOW SWITCH
RIGHT TAIL/STOP LAMP
RIGHT TAIL/TURN SIGNAL LAMP
RUN WIRE
THEFT DETERRENT MODULE (TDM) (W/ IMMOBILIZER)
TRAILER CONNECTOR
TRAILER LIGHTING
TRAILER LIGHTING CONVERTER
UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE
W/ IMMOBILIZER
W/ POWER
WHT WIRE
WINDOW
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> LEFT TAIL/TURN SIGNAL LAMP
