Chevrolet Colorado I (2004-2012) 22 23 ppl ppl class 2 serial data class 2 serial data Wiring diagram
This page shows the only wiring diagram for the component.22 23 ppl ppl class 2 serial data class 2 serial data, which is found in the car Chevrolet Colorado I (2004-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 22 23 ppl ppl class 2 serial data class 2 serial data (1 of 1)
11 10 PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA
2 1 PPL
2 SPEED
22 23 PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA
6 5 PPL PPL 1807 1807 CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA
A/T
AUX PWR 1 FUSE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT KICK PANEL)
DATA BUS -
DATA LINK CONNECTOR (DLC) (LOWER LEFT SIDE OF DASH)
DATA LINK RESISTOR
DIGITAL RADIO RECEIVER (CENTER OF DASH)
ENGINE COMPT)
ENGINE CONTROL MODULE (ECM) (RIGHT REAR OF
EXCEPT 2 SPEED
GENERATOR BATTERY CONTROL MODULE (LEFT FRONT OF ENGINE COMPT, NEAR BATTERY)
HOT AT ALL TIMES
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (BENEATH CENTER CONSOLE)
INSTRUMENT PANEL CLUSTER (IPC)
M/T
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL CLASS 2 SERIAL DATA
PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA
PPL W/ ONSTAR
PPL W/O ONSTAR
RADIO
SERIAL DATA
SERIAL DATA - SERIAL DATA + SERIAL DATA + SERIAL DATA -
TAN WIRE
TAN/WHT WIRE
TRANSFER CASE SHIFT CONTROL MODULE (UNDER DRIVER SEAT CARPET)
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPT)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (RIGHT SIDE OF DASH)
Go to component -> Computer data lines circuit -> 22 23 PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA
