Chevrolet Cobalt I (2004-2010) wpr on/off relay Wiring diagram
This page shows the only wiring diagram for the component.wpr on/off relay, which is found in the car Chevrolet Cobalt I (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wpr on/off relay (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER DASH, ON RIGHT SIDE OF CENTER CONSOLE)
DK GRN WIRE
GRY WIRE
HIGH LOW
HOT AT ALL TIMES
HOT W/ RUN/CRANK RELAY ENERGIZED
LOW HIGH PARK SWITCH
LT GRN WIRE
MIST OFF
MIST OFF INT
ORG/ WIRE
PNK WIRE
POWER PNK DISTRIBUTION SYSTEM WIRE
PPL
UNDERHOOD FUSE BLOCK
WASH
WINDSHIELD WASHER FLUID PUMP (LOWER LEFT SIDE OF WINDSHIELD WASHER RESERVOIR)
WINDSHIELD WASHER PUMP CONTROL
WINDSHIELD WIPER MOTOR PARK SWITCH SIGNAL
WINDSHIELD WIPER SWITCH SIGNAL 1
WINDSHIELD WIPER SWITCH SIGNAL 2
WINDSHIELD WIPER/WASHER SWITCH (STEERING COLUMN, ON HIGH RIGHT SIDE) LOW INT
WIPER DIODE
WIPER FUSE
WPR FUSE 15
WPR HI/LO RELAY
WPR ON/OFF RELAY
YEL WIRE
Go to component -> Wiper/washer circuit -> WPR ON/OFF RELAY
