Chevrolet Cobalt I (2004-2010) solnd lp lo volt volt Wiring diagram
This page shows the only wiring diagram for the component.solnd lp lo volt volt, which is found in the car Chevrolet Cobalt I (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram solnd lp lo volt volt (1 of 1)
ANTI-THEFT SYSTEM
AUTOMATIC TRANSMISSION SHIFT LEVER
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL SOLENOID
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER
BRAKE PEDAL POSITION SENSOR
BRN WIRE
CENTER DASH, BRK ON RIGHT SIDE REF SNS OF CENTER CONSOLE)
DIODE
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION SWITCH
LOGIC
NCA WIRE
OFF
PARK SWITCH
RED WIRE
RUN WIRE
SOLND LP LO VOLT VOLT
VOLT
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> SOLND LP LO VOLT VOLT
