Chevrolet Cobalt I (2004-2010) run/crank ign 1 voltage Wiring diagram
This page shows the only wiring diagram for the component.run/crank ign 1 voltage, which is found in the car Chevrolet Cobalt I (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram run/crank ign 1 voltage (1 of 1)
ACC VOLTAGE
BAT POS VOLTAGE
BAT POS VOLTAGE RAP FUSE SPLY VOLTAGE RUN/CRANK IGN 1 VOLTAGE IGN 1 VOLTAGE
BATTERY POSITIVE VOLTAGE
BCM 2 FUSE
BCM 3 FUSE
BODY CONTROL MODULE (BCM) (UNDER CENTER DASH, ON RIGHT SIDE OF CENTER CONSOLE)
BRN WIRE
COURTESY LAMP SPLY VOLTAGE DOOR LOCK ACTUATOR LOCK CTRL
DK BLU/WHT WIRE
DK GRN WIRE
DOOR LOCK ACTUATOR LOCK CTRL (SEDAN)
DOOR LOCK ACTUATOR UNLOCK CTRL DOOR LOCK ACTUATOR UNLOCK CTRL
DOOR LOCKS SYSTEM
ENGINE CONTROLS SYSTEM TRANSMISSIONS SYSTEM
EXTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM
EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
FUSE 8
GRY WIRE
HOT AT ALL TIMES
I/P LAMP SPLY VOLTAGE
IGN SW
LOGIC
LR STOP/TURN LAMP SUPPLY VOLTAGE COURTESY LAMP CTRL
ORG/ WIRE
PARK LAMP SPLY VOLTAGE
PNK PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM POWER WINDOWS SYSTEM POWER DISTRIBUTION SYSTEM
POWER TOPS SYSTEM
POWER WINDOWS SYSTEM
RAP FUSE SPLY VOLTAGE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RR STOP/TURN LAMP SUPPLY VOLTAGE DRIVER DR LOCK ACTUATOR UNLOCK CTRL
RUN/CRANK IGN 1 VOLTAGE
SEATS SYSTEM
SEDAN
SOUND SYSTEMS
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN WIRE
TO BCM (DIAGRAM 3 OF 4)
UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
WINDSHIELD WASHER PMP CTRL
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Body control modules circuit (2 of 4) -> RUN/CRANK IGN 1 VOLTAGE
