Chevrolet Cobalt I (2004-2010) rf wheel speed sens sig rf wheel speed sens lo ref Wiring diagram
This page shows the only wiring diagram for the component.rf wheel speed sens sig rf wheel speed sens lo ref, which is found in the car Chevrolet Cobalt I (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf wheel speed sens sig rf wheel speed sens lo ref (1 of 1)
ABS 2 FUSE
ABS 3 FUSE
ABS FUSE
BAT POSITIVE VOLT
BLK WIRE
BRAKE PRESSURE MODULATOR VALVE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LEFT FRONT WHEEL SPEED SENSOR (WSS) (INSIDE LEFT FRONT WHEEL HUB)
LF WHEEL SPEED REF LF WHEEL SPEED SIG
LT BLU WIRE
ORG/ WIRE
PNK WIRE
PUMP MOTOR
PUMP MOTOR CONTROL
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RF WHEEL SPEED SENS SIG RF WHEEL SPEED SENS LO REF
RIGHT FRONT WHEEL SPEED SENSOR (WSS) (INSIDE RIGHT FRONT WHEEL HUB)
RIGHT REAR WHEEL SPEED SENSOR (WSS) (INSIDE RIGHT REAR WHEEL HUB)
RR WHEEL SPEED SEN SIG RR WHEEL SPD SEN REF
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, without vsc (1 of 2) -> RF WHEEL SPEED SENS SIG RF WHEEL SPEED SENS LO REF
