Chevrolet Cobalt I (2004-2010) release switch signal Wiring diagram
This page shows the only wiring diagram for the component.release switch signal, which is found in the car Chevrolet Cobalt I (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram release switch signal (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER DASH, ON RIGHT SIDE OF CENTER CONSOLE)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC)
GMLAN SERIAL DATA
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
JAMB SWITCH
LOGIC
ORG/ WIRE
ORG/BLK WIRE
REAR COMPARTMENT LID RELEASE ACTUATOR (IN LATCH ASSEMBLY)
REAR COMPARTMENT LID RELEASE SWITCH
RELEASE ACTUATOR
RELEASE SWITCH SIGNAL
TAN WIRE
TAN/WHT WIRE
TRUNK PCB RELAY
TRUNK RELEASE JAMB RELAY SWITCH SIGNAL
TRUNK/ HTD SEATS FUSE
UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
WHT WIRE
Go to component -> Trunk release circuit -> RELEASE SWITCH SIGNAL
