Chevrolet Cobalt I (2004-2010) phone ind Wiring diagram
This page shows the only wiring diagram for the component.phone ind, which is found in the car Chevrolet Cobalt I (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram phone ind (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM)
BRN/WHT WIRE
BUTTON BACK LIGHTING
COURTESY LP SPLY VOLT
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
EMERGENCY IND
EMERGENCY SWITCH
GRY WIRE
HOT AT ALL TIMES INT LIGHT FUSE 27
INSIDE REARVIEW MIRROR
KEYPAD
KEYPAD GREEN LED IND
KEYPAD GREEN LED SIGNAL
KEYPAD RED WIRE
KEYPAD SIGNAL
KEYPAD SUPPLY VOLTAGE
LED SIGNAL
LOGIC
LT GRN/BLK WIRE
ONSTAR IND
ONSTAR KEYPAD
ONSTAR SWITCH
PHONE IND
PHONE SWITCH
RED LED IND WIRE
WHT WIRE
YEL/BLK WIRE
Go to component -> Automatic day/night mirror circuit, with onstar -> PHONE IND
