Chevrolet Cobalt I (2004-2010) lo beam pcb relay Wiring diagram

3 4 10 524 HEADLAMP SW SIG HIGH BEAM SIGNAL PPL 71 44 54 592 1969 317 DRL RLY CTRL HI BEAM RLY CTRL FOG LMP RLY CTRL AMBIENT LIGHT SENSOR (DASH TRIM PAD, NEAR WINDSHIELD ON DRIVER'S SIDE) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (UNDER CENTER DASH, ON RIGHT SIDE OF CENTER CONSOLE) BRN WIRE COMPUTER DATA LINES SYSTEM DK GRN WIRE DRL PCB RELAY FOG LAMP FUSE FOG LAMP IND FOG LAMP PCB RELAY FOG LAMP SWITCH FTP GRY WIRE HEAD HI BEAM PCB RELAY HIGH BEAM HIGH BEAM IND HOT AT ALL TIMES IGN INSTRUMENT PANEL CLUSTER (IPC) LEFT HEADLAMP LO BEAM PCB RELAY LOGIC LOW BEAM LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LT HI BEAM FUSE LT LO BEAM FUSE DRL FUSE OFF AUTO PARK ORG/ WIRE PARK BRAKE SW SIG PARK BRAKE SWITCH (IN CENTER CONSOLE, ATTACHED TO PARKING BRAKE) PNK WIRE PNK/WHT WIRE PPL PPL PPL PPL/WHT WIRE RIGHT FRONT FOG LAMP LEFT FRONT FOG LAMP RIGHT HEADLAMP RT HI BEAM FUSE RT LO BEAM FUSE SERIAL DATA STEERING COLUMN) TAN WIRE TAN/WHT WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER) WHT WIRE YEL WIRE YEL/BLK WIRE
