Chevrolet Cobalt I (2004-2010) lf wheel speed sig lf wheel speed ref Wiring diagram

12 VOLT 12 VOLT REF 5 VOLT REF 5 VOLT REF LOW REF 5-VOLT ABS 2 FUSE ABS 3 FUSE ABS FUSE BAT POSITIVE VOLT RF WHEEL SPEED SENS LO REF RF WHEEL SPEED SENS SIG BLK WIRE BRAKE PRESSURE MODULATOR VALVE BRN WIRE CAN BUS HIGH SERIAL CAN BUS HIGH SERIAL DATA CAN BUS LOW SERIAL DATA CAN BUS LOW SERIAL COMPUTER DATA LINES (LEFT SIDE OF SYSTEM ENGINE COMPT, UNDER COOLANT RESERVOIR) DK BLU WIRE DK GRN WIRE GROUND GROUND PUMP MOTOR GRY WIRE GRY/BLK WIRE HIGH SERIAL CAN BUS HOT AT ALL TIMES HOT IN RUN OR START LEFT FRONT WHEEL SPEED SENSOR (WSS) (INSIDE LEFT FRONT WHEEL HUB) LEFT REAR WHEEL SPEED SENSOR (WSS) (INSIDE LEFT REAR WHEEL HUB) LF WHEEL SPEED SIG LF WHEEL SPEED REF LOW REF LOW SERIAL CAN BUS LR WHEEL SPD SEN SIG LR WHEEL SPD SENS LO REF LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PNK IGN 1 VOLT WIRE PNK WIRE PNK/BLK WIRE PUMP MOTOR CONTROL RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT WHEEL SPEED SENSOR (WSS) (INSIDE RIGHT FRONT WHEEL HUB) RIGHT REAR WHEEL SPEED SENSOR (WSS) (INSIDE RIGHT REAR WHEEL HUB) STEERING ANGLE SENSOR STEERING WHEEL POSITION SEN TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER) WHT WIRE YAW, LATERAL ACCELEROMETER SENSOR YEL WIRE
