Chevrolet Cobalt I (2004-2010) i/p lamp supply voltage Wiring diagram
This page shows the only wiring diagram for the component.i/p lamp supply voltage, which is found in the car Chevrolet Cobalt I (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram i/p lamp supply voltage (1 of 1)
ACC VOLTAGE
ANTI-THEFT SYSTEM AIR CONDITIONING SYSTEM
BAT POS VOLTAGE
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER DASH, ON RIGHT SIDE OF CENTER CONSOLE)
BRN WIRE
CRUISE CONTROL SYSTEM ELECTRONIC POWER STEERING SYSTEM
FROM BCM (DIAGRAM 2 OF 4)
GROUND
GRY WIRE
I/P LAMP SUPPLY VOLTAGE
IGN 1 VOLTAGE
INSTRUMENT PANEL LAMP SUPPLY VOLTAGE INSTRUMENT PANEL LAMP SUPPLY VOLTAGE
LOGIC
ORG/ WIRE
PNK PNK PNK PNK PNK WIRE
PNK PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM AIR CONDITIONING SYSTEM
POWER DISTRIBUTION SYSTEM POWER DISTRIBUTION SYSTEM
RED/WHT WIRE
RUN/CRANK VOLTAGE IGN 3 VOL
SOUND SYSTEMS
SOUND SYSTEMS DOOR LOCKS SYSTEM
WINDSHIELD WASHER PUMP CTRL INSTRUMENT PANEL LAMP SUPPLY VOLTAGE
WIPER/WASHER SYSTEM INTERIOR LIGHTS SYSTEM
YEL WIRE
Go to component -> Body control modules circuit (3 of 4) -> I/P LAMP SUPPLY VOLTAGE
