Chevrolet Cobalt I (2004-2010) high speed gmlan serial data bus + Wiring diagrams
This page contains all the electrical diagrams for the component. high speed gmlan serial data bus +, in which he is found in the car Chevrolet Cobalt I (2004-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram high speed gmlan serial data bus + (1 of 2)
2.4L/2.2L W/ A/T
2.4L/2.2L W/ M/T
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DATA LINK CONNECTOR (DLC) (LOWER LEFT OF DASH, NEAR HOOD RELEASE)
DIGITAL RADIO RECEIVER (CENTER REAR SHELF, UNDER TRIM PAD)
DK GRN WIRE
DLC FUSE
ENGINE CONTROL MODULE (ECM) (2.2L/2.4L) (LEFT SIDE OF ENGINE COMPT, IN FRONT OF
HIGH HIGH SPEED
HIGH SPEED GMLAN SERIAL DATA BUS +
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LOW SPEED GM LAN SERIAL DATA
LOW SPEED GMLAN SERIAL DATA
RADIO
RED/WHT WIRE
SERIAL DATA BUS + HIGH SPEED GMLAN
TAN WIRE
TAN/BLK WIRE
THEFT DETERRENT CONTROL MODULE (IN STEERING COLUMN, NEAR IGNITION SWITCH)
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
W/ ACTIVE BRAKE
W/ ONSTAR W/ ONSTAR
W/ VSC
W/O ACTIVE BRAKE
W/O ONSTAR
W/O VSC
Go to component -> Computer data lines circuit -> HIGH SPEED GMLAN SERIAL DATA BUS +
Wiring diagram high speed gmlan serial data bus + (2 of 2)
AMBIENT LIGHT SENSOR (DASH TRIM PAD, NEAR WINDSHIELD ON DRIVER'S SIDE)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER DASH, ON RIGHT SIDE OF CENTER CONSOLE)
BPP SENS SIG
BRAKE PEDAL POSITION SENSOR
BRN WIRE
BRN/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
CHMSL FUSE
CHMSL RELAY
CHMSL SPLY VOLT
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRL AMBIENT LIGHT SENS LOW REF
DRL AMBIENT LIGHT SENS SIG
GROUND
GRY WIRE
HAZARD SW SIG
HAZARD SWITCH
HEAD OFF HEADLAMP SWITCH
HIGH SPEED GMLAN SERIAL DATA BUS +
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT MARKER LAMP
LEFT PARK/TURN SIGNAL LAMP
LEFT TURN SIG LAMP
LEFT TURN SIG SW SIG
LEFT TURN SIGNAL IND
LOGIC
LOW REF
LOW SPEED GMLAN SERIAL DATA
LT BLU WIRE
LT GRN/BLK WIRE
PARK AUTO
PARK LAMP RLY CTRL
PARK LAMP SPLY VOLT LEFT REAR STOP/TURN
PARK LAMP SW SIG
PRK LAMP FUSE
PRK LAMP PCB RELAY
RIGHT FRONT MARKER LAMP
RIGHT LEFT
RIGHT PARK/TURN SIGNAL LAMP
RIGHT REAR STOP/TURN
RIGHT TURN SIG LAMP
RIGHT TURN SIG SW SIG
RIGHT TURN SIGNAL IND
TAN WIRE
TAN/BLK WIRE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
TURN SWITCH
UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> HIGH SPEED GMLAN SERIAL DATA BUS +
