Chevrolet Cobalt I (2004-2010) dr door unlock pcb relay Wiring diagram
This page shows the only wiring diagram for the component.dr door unlock pcb relay, which is found in the car Chevrolet Cobalt I (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dr door unlock pcb relay (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER DASH, ON RIGHT SIDE OF CENTER CONSOLE)
DOOR LOCK PCB RELAY
DOOR UNLOCK CTRL
DOOR UNLOCK PCB RELAY
DOORS LOCK CTRL
DR DOOR UNLOCK CTRL
DR DOOR UNLOCK PCB RELAY
DR LCK FUSE 26
DRIVER DOOR UNLOCK LOCK SWITCH
GRY WIRE
HAZARD SWITCH SIG
HORN RELAY CTRL
HORNS SYSTEM
HOT AT ALL TIMES
LOCK
LOCK UNLOCK
LOCK/UNLOCK SIG
LOGIC
PASSENGER DOOR LOCK SWITCH
POWER WINDOWS SYSTEM
TAN WIRE
W/ POWER WINDOWS, REMOTE OUTSIDE MIRRORS
WHT WIRE
Go to component -> Power door locks circuit (2 of 2) -> DR DOOR UNLOCK PCB RELAY
