Chevrolet Cobalt I (2004-2010) close vent off Wiring diagram
This page shows the only wiring diagram for the component.close vent off, which is found in the car Chevrolet Cobalt I (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram close vent off (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER DASH, ON RIGHT SIDE OF CENTER CONSOLE)
CLOSE
CLOSE OFF
CLOSE VENT OFF
DK GRN WIRE
HOT W/ RAP RELAY ENERGIZED
LIMIT SWITCH
LT BLU WIRE
LT GRN WIRE
OPEN/ VENT
S ROOF FUSE 20
SUNROOF MOTOR (BETWEEN SUN VISORS, IN HEADLINER)
SUNROOF SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> CLOSE VENT OFF
