Chevrolet Cobalt I (2004-2010) brake fluid level sensor signal Wiring diagrams
This page contains all the electrical diagrams for the component. brake fluid level sensor signal, in which he is found in the car Chevrolet Cobalt I (2004-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brake fluid level sensor signal (1 of 2)
2.2L 2.4L
ABS INDICATOR
BATT POS VOLTAGE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER DASH)
BRAKE FLUID LEVEL SENSOR SIGNAL
BRAKE FLUID LEVEL SWITCH (IN REAR OF ENGINE COMPT, ATTACHED TO MASTER CYLINDER)
BRAKE INDICATOR
CLSTR FUSE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT, IN FRONT OF
GROUND
HI SPD GMLAN SER DATA -
HI SPD GMLAN SERIAL DATA
HOT AT ALL TIMES
IGN
INSTRUMENT PANEL CLUSTER
LEFT REAR WHEEL SPEED SENSOR (WSS) (INSIDE LEFT REAR WHEEL HUB)
LO SPD GMLAN SERIAL DATA
LOGIC
LOW SPD GMLAN SER DATA
LT BLU WIRE
ON RIGHT SIDE OF CENTER CONSOLE)
ORG/ WIRE
PARK BRAKE SWITCH (IN CENTER CONSOLE, ATTACHED TO PARKING BRAKE)
PARK BRAKE SWITCH SIGNAL
PNK WIRE
RED WIRE
RED/WHT WIRE
SERIAL DATA
TAN WIRE
TAN/BLK WIRE
TRACTION OFF IND
UNDERHOOD FUSE BLOCK
Go to component -> Anti-lock brakes circuit, without vsc (2 of 2) -> BRAKE FLUID LEVEL SENSOR SIGNAL
Wiring diagram brake fluid level sensor signal (2 of 2)
2.2L 2.4L
ABS INDICATOR
BATT POS VOLTAGE
BLK WIRE
BLK/WHT WIRE
BLU LT WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER DASH, ON RIGHT SIDE OF
BRAKE BOOSTER VACUUM SENSOR
BRAKE FLUID LEVEL SENSOR SIGNAL
BRAKE FLUID LEVEL SWITCH (IN REAR OF ENGINE COMPT, ATTACHED TO MASTER CYLINDER)
BRAKE INDICATOR
CENTER CONSOLE
CLSTR FUSE
COMPUTER DATA LINES SYSTEM
DATA - HI SPD GMLAN SERIAL
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT, IN FRONT OF
GROUND
GRY WIRE
HI SPD GMLAN SER DATA -
HI SPD GMLAN SERIAL DATA
HOT AT ALL TIMES
IGN
INSTRUMENT PANEL CLUSTER
LO SPD GMLAN SERIAL DATA
LOGIC
LOW SPD GMLAN SER DATA
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
PARK BRAKE SWITCH (IN CENTER CONSOLE, ATTACHED TO PARKING BRAKE)
PNK WIRE
PRAKE BRAKE SWITCH SIGNAL
RED/WHT WIRE
SERIAL DATA
SWITCH
TAN WIRE
TAN/BLK WIRE
TRACTION CONTROL
TRACTION CONTROL SWITCH SIGNAL
TRACTION OFF IND
UNDERHOOD FUSE BLOCK
Go to component -> Anti-lock brakes circuit, with vsc (2 of 2) -> BRAKE FLUID LEVEL SENSOR SIGNAL
