Chevrolet Cobalt I (2004-2010) 9 10 11 12 13 14 low speed gmlan serial data Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 L AUDIO SIG (+) R AUDIO SIG (+) 1 2 3 4 5 6 7 8 BATT 9 10 11 12 13 14 LOW SPEED GMLAN SERIAL DATA BARE BARE 8 2 1 DRAIN WIRE LOW REFERENCE CELL TELEPHONE VOICE SIG BLK/WHT WIRE BLUNT CUT) BODY CONTROL MODULE (BCM) (UNDER CENTER DASH, ON RIGHT SIDE OF CENTER CONSOLE) BRN WIRE BRN/WHT WIRE CELL VOICE SIG COAX COAX ANTENNA SIG COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE GROUND GRY WIRE HOT AT ALL TIMES LEFT FRONT DOOR SPEAKER LEFT REAR SPEAKER LT BLU WIRE LT GRN WIRE MUTE ORG/BLK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM RADIO RADIO ANTENNA MODULE RDO FUSE 23 RED WIRE RED/WHT WIRE RF SPKR OUT (-) RF SPKR OUT (+) LF SPKR OUT (-) LF SPKR OUT (+) GROUND RIGHT FRONT DOOR SPEAKER RIGHT REAR SPEAKER RIGHT STEERING WHEEL CONTROL SWITCH SATELLITE RADIO CIRCUIT STRG WHEEL CTRL SIG TAN WIRE TAN/WHT WIRE VOL UP VOL DOWN SRCE WHT WIRE WHT/BLK WIRE YEL WIRE
