Chevrolet Cobalt I (2004-2010) 72 68 rear defog rly ctrl rear defog sw sig Wiring diagram
This page shows the only wiring diagram for the component.72 68 rear defog rly ctrl rear defog sw sig, which is found in the car Chevrolet Cobalt I (2004-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 72 68 rear defog rly ctrl rear defog sw sig (1 of 1)
72 68 REAR DEFOG RLY CTRL REAR DEFOG SW SIG
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER DASH, ON RIGHT SIDE OF CENTER CONSOLE)
DEFOG SWITCH
DEFOGGER INDICATOR
HOT AT ALL TIMES
HVAC CONTROL MODULE (CENTER OF DASH, BELOW RADIO)
LOGIC
LT BLU WIRE
PPL
REAR DEFOG FUSE
REAR DEFOG RELAY
REAR WINDOW DEFOGGER GRID
UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
WHT WIRE
Go to component -> Defoggers circuit -> 72 68 REAR DEFOG RLY CTRL REAR DEFOG SW SIG
