6.5l (vin f), transmission circuit for Chevrolet Chevy Van G2500 (1996-1998)

1-2 SHIFT SOL 1-2 SHIFT SOLENOID 2-3 SHIFT SOL 2-3 SHIFT SOLENOID A/T ISS SENS HI IN A/T ISS SENS LO IN ACCELERATOR PEDAL POSITION (APP) MODULE (THROTTLE PEDAL MOUNT) APP 1 SIGNAL IN APP 2 SIGNAL IN APP 3 SIGNAL IN AUTO TRANSMISSION INPUT SHAFT SPEED SENSOR (INSIDE FRONT OF TRANSMISSION) AUTOMATIC TRANSMISSION BATTERY IN BLK WIRE BLK/WHT WIRE BRAKE FUSE 18 BRAKE SWITCH ASSEMBLY (ON BRAKE PEDAL BRACKET) BRAKE SWITCH IN BRN WIRE BRN/WHT WIRE CLASS II DATA DIESEL FUEL FUSE DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE ECM-B FUSE ECT SENSOR IN ENGINE COOLANT TEMP SENSOR (TOP FRONT OF ENGINE) GAUGES FUSE 4 GROUND GRY WIRE HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK IGNITION IN INSTRUMENT CLUSTER LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE MALFUNCTION INDICATOR LAMP MIL CONTROL ORG/ WIRE PCM GROUND PCS SOL HI OUT PCS SOL LO OUT PNK POWER WIRE PNK WIRE POWERTRAIN CONTROL MODULE (BEHIND CENTER OF DASH) PPL PPL DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) PPL/WHT WIRE PRESS CTRL HI SOLENOID RED WIRE RED/BLK WIRE SENSOR GROUND STOP FUSE 1 STOPLAMP SWITCH IN TAN/WHT WIRE TCC PWM SOL TCC PWM SOLENOID TFT SENSOR IN TRANS FLUID TEMP SENSOR TRANS FUSE 20 TRANS RANGE "A" TRANS RANGE "B" TRANS RANGE "C" TRANS RANGE PRESSURE SWITCH ASSEMBLY UNDERHOOD FUSE/RELAY CENTER VEHICLE SPEED SENSOR (VSS) BUFFER (LEFT SIDE OF DASH) VSS HI IN VSS IN VSS LO IN VSS OUT WHT WIRE YEL WIRE YEL/BLK WIRE
