Chevrolet Chevy Van G1500 (1996-1998) powertrain control module Wiring diagrams
This page contains all the electrical diagrams for the component. powertrain control module, in which he is found in the car Chevrolet Chevy Van G1500 (1996-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram powertrain control module (1 of 2)
A/C COMPRESSOR CLUTCH COIL
AMBULANCE PACKAGE
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR RESISTOR/ RELAY
BLUNT CUT)
BRAKE PRESSURE DIFFERENTIAL SWITCH
CENTER HIGH MOUNTED STOPLAMP CENTER HIGH MOUNTED STOPLAMP
DATA LINK CONNECTOR
DIESEL ENGINES
DIODE
ELECTRONIC BRAKE CONTROL MODULE
EVO/ PASSLOCK MODULE
FRONT AUXILIARY HVAC CONTROL MODULE HEATER AND A/C CONTROL LOGIC MODULE
FUEL HEATER
FUEL LIFT PUMP
FUEL PUMP RELAY
FUEL SENDER BUFFER MODULE
GLOW PLUG RELAY
HORNS
INSTRUMENT CLUSTER
LEFT BACK-UP LAMP
LEFT REAR PARK/ STOP LAMP
LEFT REAR PARK/ TURN LAMP
NCA WIRE
PARK/ NEUTRAL POSITION SWITCH
PASSENGER VANS ONLY
POWERTRAIN CONTROL MODULE
REAR AUXILIARY HVAC CONTROL MODULE
RIGHT BACK-UP LAMP LICENSE LAMP
RIGHT POWER SEAT SWITCH
RIGHT REAR DOOR JAMB SWITCH SIDE DOOR JAMB SWITCH
RIGHT REAR PARK/ STOP LAMP
RIGHT REAR PARK/ TURN LAMP
STARTER RELAY
TAN/WHT WIRE
UNDERHOOD FUSE-RELAY CENTER
UNDERHOOD LAMP
UNDERHOOD REEL LAMP
VEHICLE SPEED SENSOR BUFFER
W/ AUXILIARY HEAT ONLY
W/ AUXILIARY HEAT, A/C
WATER IN FUEL INDICATOR
Go to component -> Ground distribution circuit (3 of 3) -> POWERTRAIN CONTROL MODULE
Wiring diagram powertrain control module (2 of 2)
35 CM FROM BREAKOUT TO CONNECTOR NEAR STARTER)
4.3L (ENGINE HARNESS, APPROX 4 CM FROM FUEL INJECTOR HARNESS BREAKOUT)
5.0L, 5.7L, 7.4L
6.5L
7.4L
A/C COMPRESSOR ENABLE RELAY UNDERHOOD FUSE-RELAY CENTER
APPROX 66 CM FROM CONNECTOR BREAKOUT NEAR STARTER)
BULKHEAD CONNECTOR BREAKOUT)
CAMSHAFT POSITION SENSOR VEHICLE CONTROL MODULE FUEL INJECTORS 1, 3, 5,, 7
CRANKSHAFT POSITION SENSOR
CRANKSHAFT POSITION SENSOR HEATED OXYGEN SENSOR, BANK 2 SENSOR 1
DIESEL
ECM 1 FUSE
ENG 1 FUSE
ENGINE SHUT OFF SOLENOID
EVAP EMISSION CANISTER PURGE VALVE SECONDARY AIR INJECTION PUMP RELAY
EVAPORATIVE EMISSION CANISTER PURGE VALVE
EVAPORATIVE EMISSION VENT VALVE
EVAPORATIVE EMISSIONS VENT VALVE MASS AIR FLOW SENSOR
FROM CONNECTOR BREAKOUT NEAR STARTER)
FROM IGNITION SWITCH (DIAGRAM 1 OF 4)
FUEL HEATER
FUEL INJECTORS 1, 3, 5, 7 VEHICLE CONTROL MODULE
FUEL INJECTORS 2, 4, 6, 8 IGNITION CONTROL MODULE
FUEL INJECTORS 2, 4, 6,, 8
FUEL SOL FUSE
FUEL SOLENOID DRIVER
GLOW PLUG RELAY WASTE GATE SOLENOID
HEATED OXYGEN SENSOR (BANK 1, SENSOR 3)
HEATED OXYGEN SENSOR BANK 1 SENSOR 1
HEATED OXYGEN SENSOR BANK 1 SENSOR 2
HEATED OXYGEN SENSOR BANK 1 SENSOR 2 HEATED OXYGEN SENSOR BANK 2 SENSOR 2
HEATED OXYGEN SENSOR BANK 2 SENSOR 1
HEATED OXYGEN SENSOR, BANK 1 SENSOR 1 MASS AIR FLOW SENSOR
HEATED OXYGEN SENSOR, BANK 1 SENSOR 2 HEATED OXYGEN SENSOR, BANK 1 SENSOR 3
IGN E MINI FUSE
IGNITION COIL
IGNITION CONTROL MODULE
PNK WIRE
POWERTRAIN CONTROL MODULE
RIGHT HEATED OXYGEN SENSOR BREAKOUT)
TO I/P FUSE BLOCK (DIAGRAM 4 OF 4) PNK WIRE
UNDERHOOD FUSE-RELAY CENTER
VEHICLE CONTROL MODULE IGNITION CONTROL MODULE FUEL INJECTORS 1, 3, 5
WATER IN FUEL INDICATOR SENSOR
Go to component -> Power distribution circuit (3 of 4) -> POWERTRAIN CONTROL MODULE
