Chevrolet Chevy Van G1500 (1996-1998) base models upfitter package Wiring diagram

195 156 LOCK OUT DOME LAMPS 39 157 1455 PNK IGNITION DOME LMP OFF PROGRAM SIG WIRE BASE MODELS UPFITTER PACKAGE BATT (B+) BATT (B+) RR DOOR UNLK PASS DRS UNLK BLK WIRE BLK/WHT WIRE CONVENIENCE CENTER (LEFT SIDE OF DASH) DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DOOR JAMB SWITCH HARNESS BREAKOUT) DRIVER DR UNLK UNLOCK IN GAUGES FUSE 4 GROUND GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK (LEFT SIDE OF DASH) PWR ACCY FUSE A LEFT DOOR LOCK SWITCH LEFT FRONT DOOR LOCK ACTUATOR LOCK LOCK SIG UNLOCK SIG LT BLU WIRE ORG/ WIRE PNK WIRE POWER DOOR LOCK CONTROL MODULE (LEFT KICK PANEL) POWER DOOR LOCK RELAY (BEHIND RIGHT CENTER OF DASH) REAR DOOR LOCK ACTUATOR REMOTE CONTROL DOOR LOCK RECEIVER (UPPER RIGHT KICK PANEL) RIGHT BODY HARNESS RIGHT DOOR LOCK SWITCH RIGHT FRONT DOOR LOCK ACTUATOR RIGHT REAR DOOR LOCK SWITCH SIDE DOOR CONTACTOR (RIGHT "B" PILLAR) SIDE DOOR JAMB SWITCH SIDE DOOR LOCK ACTUATOR SIDE DOOR SW BATTERY (B+) LOCK SIG SWITCH BREAKOUT) (W/ PASSENGER POWER SEAT ONLY) TAN WIRE UNLOCK UPFITTER PACKAGE BASE MODELS WHT WIRE WHT/BLK WIRE
