Courtesy lamps circuit, base for Chevrolet Chevy Van G10 (1985-1995)
Courtesy lamps circuit, base
BATTERY JUNCTION BLOCK
BLK WIRE
FRONT DOME LAMP
FUSE BLOCK
FUSIBLE LINK (20 GA-RUST)
HORN/DM FUSE
HOT AT ALL TIMES
IN LINE UNDERHOOD LAMP FUSE
LEFT DOOR JAMB SWITCH
LIGHT SWITCH DOME SWITCH
NCA WIRE
ORG/ WIRE
REAR DOME LAMP
RED WIRE
RIGHT DOOR JAMB SWITCH
SIDE DOOR JAMB SWITCH
UNDERHOOD LAMP
WHT WIRE
