Wiring diagram engine performance 4.3l (vin z)s, 4l60-e a/t (2 of 3) for Chevrolet Chevy Van G10 (1985-1995)

1995 VFTC 23 24 PNK WIRE 3 121 PNK WIRE 4.3L ONLY ACCY AUXILIARY FUSE BLOCK BLK WIRE BLK/RED WIRE BLK/YEL WIRE BRAKE FUSE BRN WIRE BRN/WHT WIRE BULB TEST DISTRIBUTOR (CENTER REAR OF ENGINE) DK BLU WIRE DK GRN/WHT WIRE ENGINE COOLANT TEMPERATURE SENSOR (ON INTAKE MANIFOLD) FUSE BLOCK GAGES FUSE GRY WIRE HOT AT ALL TIMES HOT IN RUN HOT IN RUN, BULB TEST OR START IGNITION COIL (TOP RIGHT REAR OF ENGINE) IGNITION SWITCH INSTRUMENT CLUSTER KNOCK SENSOR (LEFT REAR OF ENGINE, NEAR OIL PRESSURE SENDER) LOCK OFF LT BLU/WHT WIRE LT GRN WIRE MALFUNCTION (SERVICE ENGINE SOON) INDICATOR MANIFOLD ABSOLUTE PRESSURE SENSOR (ABOVE VALVE COVER) NCA WIRE ORG/BLK WIRE PNK WIRE PNK/BLK WIRE PNK/WHT WIRE PPL PPL 1 2 3 4 PPL 21 22 PPL 3 4 PPL/WHT WIRE RED WIRE RED/BLK WIRE RUN WIRE TACHOMETER TEST LEAD TAN/BLK WIRE TCC/BRAKE SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) THROTTLE POSITION SENSOR (ON THROTTLE BODY) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
