Courtesy lamps circuit, without upfitter package for Chevrolet Chevy Express H2500 (2003-2003)

AUXILIARY 1 FUSE 32 BLK WIRE BODY CONTROL MODULE (BCM) (LOWER RIGHT SIDE OF I/P) BODY FUSE BLOCK (BELOW DRIVERS SEAT) CARGO CARGO DOOR LATCH ASSEMBLY CTSY CTSY LPS SUPPLY BATTERY DK BLU/WHT WIRE DOME DOME DEFEAT DOOR OPEN SW SIG REAR DOOR AJAR CTSY LAMPS ON SIG LF DOOR SW SIG DRIVER DOOR LATCH ASSEMBLY FL WORK LMP SIG FL WORK LMP CTRL GRY/BLK WIRE HEADLAMP AND PANEL DIMMER SWITCH HNDL HNDL DOME HOT AT ALL TIMES LEFT REAR DOOR JAMB SWITCH LT GRN WIRE NOT USED ORG/ WIRE PASSENGER DOOR LATCH ASSEMBLY POWER PPL PPL DEFEAT SW SIG REAR DOME LAMP RED WIRE RED/WHT WIRE RIGHT REAR DOOR JAMB SWITCH SPLICE TAN WIRE TBC 2 FUSE 18 UNDERHOOD FUSE BLOCK (ON LEFT FRONT FENDER) W/ POWER DOOR LOCKS W/O POWER DOOR LOCKS YEL/BLK WIRE

BLK WIRE CARGO/CUTAWAY DK BLU/WHT WIRE DOME DOME FLOUR- ESCENT FUSE 2 DOME FLUORESCENT WORK LAMP 1 DOME FLUORESCENT WORK LAMP 2 DOME FLUORESCENT WORK LAMP RELAY (2004) (ATTACHED TO LEFT "B" PILLAR) DOME RDNG FRONT COURTESY/ READING LAMPS FRONT COURTESY/ READING LIGHT GRY/BLK WIRE LEFT FRONT DOME FLUORESCENT WORK LAMP LEFT REAR DOME FLUORESCENT WORK LAMP LEFT VANITY MIRROR LAMP MID COURTESY/ READING LAMPS NCA WIRE ORG/ WIRE PASSENGER RDNG REAR COURTESY READING LAMPS REAR FUSE BLOCK (ATTACHED TO LEFT "B" PILLAR) RED WIRE RIGHT DOME FLUORESCENT WORK LAMP RIGHT VANITY MIRROR LAMP UNDERHOOD LAMP
